Haven't seen this rendering before. I don't believe Metrolinx has released an actual track plan of how many platforms they are planning on consolidating at Union, correct? This shows platform's 8 & 9, which are approximately in the middle of the train shed today. I'd be very interested to see the "final" configuration of Union post GO-RER. This one at least shows the removal of tracks 10&11..
